Container Ship Gearbox by Meenyon-1

Inquiry

more products

Marine Gearbox

Hydraulic Marine Clutch

Aftermarket of Marine Gearbox

Marine Unit solution

Send your inquiry

Product details of the container ship gearbox

Product Information

With well-selected materials, Meenyon container ship gearbox boasts a pretty impressive set of features. We organized a quality circle to detect and solve any quality problems in the production process, effectively ensuring the quality of products. The product has got a high level of customer satisfaction, showing great potential for wider market application.

Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

OPTIONS

● Mechanical joint clutch

Specification

Item	Description	Model 16A
01	Engine speed: 1000-2000 rpm; max 32.2 hp at 2000 rpm
02	Ratio :1	2.07	2.48	2.95	3.35	3.83
03	Rate (hp/rpm)	0.016	0.016	0.016	0.016	0.016
04	Bell housing: 2015C, 395, #3, #4				Flywheel: 2105C, 395, 11.5”, 10”
05	Overall L×W×H: 422×325×563 mm				Dry weight: 84kg
06	Centre distance: 135 mm;
07	Recommend engine:MWM D226-2; HATZ 3M31
08	Rated propeller thrust: 3.5 kN

Dimension

Model 16A
C	135 mm
S
F
L
R

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Feature

• Our company's professional service team provides all-round professional and suitable services for customers according to the different needs of each customer.
• Traffic convenience including easy and open highway access and the great geographic location is conducive to the transportation of Marine Gearbox,Marine Gearbox Parts,Marine Power System Solution,Marine Hydraulic Clutch.
• Since the establishment in we have continuously innovated our business model and established and improved the management system of modern enterprise. So we have finally found an industrialized development path.
We supply our products of good quality and affordable price in long term. Please feel free to consult us!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
