Company Advantages
· After many times of iterations, sole weight of marine transmissions for sale'body frame is effectively decreased.
· The rigorous testing procedures ensure that the product quality is consistently at its best.
· MEENYON possesses whole distributing net and supplying resource.
Features
● Durable structure of driving gear bearing
● Tapered roller thrust bearing for output shaft thrust
● Hydraulic clutches of forward and reverse
● Quality Control System ISO/IATF16949:2016
● Quiet operation with precise gearing.
● Compact design
● Go Home function (emergency bolt application)
Specification
|
Item |
Description |
|
Model T600A |
|||||||
|
01 |
Engine speed: 1000-2100 rpm; max 1267 hp at 2100 rpm |
|||||||||
|
02 |
Reduction Ratio :1 |
6.97 | 7.51 | 8.04 | 8.66 | 9.35 | ||||
|
03 |
Rate (hp/rpm) |
0.523 | 0.487 | 0.453 | 0.390 | |||||
|
04 |
Bell housing: #00,#0, #1 |
Flywheel: 14”, 16”,18”,21” |
||||||||
|
05 |
Overall L×W×H: 821×1214×1271 mm |
Dry weight: 1650 kg |
||||||||
|
06 |
Centre distance: 415 mm |
|||||||||
|
07 |
Recommend engine: KTA38-M940, CAT3508TA TBD234V16… |
|||||||||
|
08 |
Rated propeller thrust: 90 KN |
|||||||||
Dimension
|
Model T600A |
|
|
C |
415 mm |
|
S |
365 mm |
|
F |
821 mm |
|
L |
442 mm |
|
R |
442 mm |
faq
Company Features
· With the equipment of advanced technology, MEENYON can produce sophisticated marine transmissions for sale.
· Our company takes pride in investing in a wide range of production facilities. These facilities are highly efficient and allow us to produce products complying with the highest standards.
· In order to meet the needs of the market, Meenyon will constantly develop new products. Welcome to visit our factory!
Application of the Product
Meenyon's marine transmissions for sale can be used in multiple industries and fields.
With professional engineers and technicians in our company, Meenyon is able to provide one-stop and comprehensive solutions for customers.
Product Comparison
Compared with similar products, the marine transmissions for sale of Meenyon is more strict in the selection of raw materials. The specific aspects are as follows.
Enterprise Advantages
Meenyon has a solid team of professional skills, with modern awareness and superb skills to provide customers with strong technical support.
Through the application of online information service tools, our company implements clear management of after-sales service. With the improvement of the efficiency and quality of after-sales service, each customer could enjoy high-quality after-sales service.
Our company sticks to the road of modern civilization development. We regard 'honesty, responsibility, environmental protection, development' as our enterprise spirit and we adhere to our development strategy of 'excellence for progress, innovation for development'. Based on that, we strive to enhance our enterprise competitiveness and develop modern industry.
Since built in Meenyon has been managing steadily step by step. Up to now, we have been developing for years and has accumulated rich industry experience.
Through continuous improvement of sales channels, our company has established an unobstructed market channel and sales network at home and abroad with our major distribution outlets. It expands the visibility of our products.
