Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

Options

● Mechanical, pneumatic or electrical remote control

Specification

Item	Description			Model 27000
01	Engine speed: 500-1400 rpm; max 3849 hp at 1400 rpm
02	Reduction Ratio :1	1.54	2.03		2.58	3.09	3.48	3.95	4.47
03	Rate (hp/rpm)	2.749	2.749		2.749	2.749	2.749	2.749	2.347
04	Bell housing: NO						Flywheel: main engine
05	Overall L×W×H: 1613×1670×1650 mm						Dry weight: 4700 kg
06	Centre distance: 490 mm
07	Recommend engine:
08	Rated propeller thrust: 270 KN

Dimension

Model 2700
C	490 mm
S	mm
F	mm
L	mm
R	mm

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Advantages

· Meenyon marine transmissions is offered in various designed styles in order to meet different requirements.

· The product undergoes in-house quality assurance procedures.

· This product has diverse features suiting the requirements of the market.

Company Features

· Over the years, Meenyon has been providing customers with marine transmissions and unparalleled customer service, making us one of the most effective suppliers in the industry.

· The internal quality management system has existed since the very first days of the factory's activity. This system targets controlling the entire range of production activities to ensure high product quality.

· We are committed to maintaining and developing robust corporate governance practices. We intend to ensure the delivery of high-quality products and services and maintain the highest standards of ethics.

Application of the Product

The marine transmissions produced by our company is suitable for various occasions in industry.

Meenyon insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
