Marine Gearbox Manufacturers Medium and Heavy Duty Gearbox Wholesale - Meenyon

Inquiry

Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

OPTIONS

● PTO

● Mechanical, pneumatic or electrical remote control

Specification

Item	Description	Model MA142A
01	Engine speed: 1500-2500 rpm; max 100.6 hp at 2500 rpm
02	Ratio :1	1.97	2.52	3.03	3.54	3.95	4.50	5.06	5.47
03	Rate (hp/rpm)	0.040	0.040	0.040	0.035	0.031	0.025	0.021	0.017
04	Bell housing: #2, #3				Flywheel: 10”, 11.5”
05	Overall L×W×H: 308×520×540 mm				Dry weight: 140kg
06	Centre distance: 142 mm;
07	Recommend engine:CUMMINS 4B3.9-M, MWMD226-4
08	Rated propeller thrust: 8.5 kN

Dimension

Model MA142A
C	142 mm
S
F
L
R

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Advantages

· It will help a lot for the popularity of Meenyon to perform the design.

· Statistical quality control technology is adopted to ensure product quality is stable.

· Meenyon has a wholly-owned sales subsidiary in many regions in China.

Company Features

· Meenyon has built its reputation for manufacturing high-quality marine gearbox manufacturers, becoming one of the global manufacturers.

· Our company has state-of-the-art manufacturing facilities. In fact, we have made a significant investment in the equipment to allow for more throughput and a better production process.

· Meenyon intends to be among the very influential high-end brands in producing marine gearbox manufacturers. Contact us!

Application of the Product

Multiple in function and wide in application, marine gearbox manufacturers can be used in many industries and fields.

With Internet technology, we provide a one-stop solution for practical and effective implementation of related problems encountered in the process of purchasing products.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
