Company Advantages

· The production equipment of Meenyon marine gear box is advanced and meets the requirements of international standards.

· Our product is used and known for its reliability.

· Meenyon provides technical support to customers in the process of pre-sales , sales and after sales.

Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

Specification

Item	Description	Model T1400-2
01	Engine speed: 600-19000 rpm; max 2624 hp at 1900 rpm.
02	Ratio :1	10.47	11.15	11.50	12.01	12.43	12.96	13.41	14.02	14.53	15.10	15.53	16.00	16.52	17.01	17.60	17.99	18.41	19.07
03	Rate (hp/rpm)	1.381	1.381	1.381	1.381	1.336	1.251	1.236	1.184	1.143	1.016	0.988	0.959	0.929	0.902	0.872	0.853	0.833	0.805
04	Bell housing: No									Flywheel: main engine
05	Overall L×W×H: 1279×1600×2100mm									Dry weight: 5500kg
06	Centre distance: 722mm ;
07	Recommend engine:
08	Rated propeller thrust: 220kN

Dimension

Model T1400-2
C	722mm
S
F
L
R

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Features

· Meenyon has always been focusing on the professional production of marine gear box for many years. Now, we have taken the lead in this industry in China.

· The scientific research and technological strength of Meenyon is the highest level of domestic technology.

· We never stop striving to become the top manufacturer in this industry in the international market. We have been doing our best to expand international cooperation and expand our capacity in product customization.

Application of the Product

Our marine gear box is widely used in multiple industries and fields.

From the customer's point of view, we provide our customers with a complete, fast, efficient and feasible solution to solve their problems.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
