Company Advantages

· Meenyon has been equipped with professional team to design more attractive high speed gearbox.

· It has passed comprehensive performance tests before leaving the factory to ensure product quality.

· Meenyon has million square meters of production workshop.

Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● 5° down angle on output shaft

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

OPTIONS

● Mechanical or electrical remote control

Specification

Item	Description	Model A302 7°
01	Engine speed: 1000-2300 rpm; max 575 hp at 2300 rpm
02	Reduction Ratio :1	1.50	1.96	2.57	2.95
03	Rate (hp/rpm)	0.250	0.250	0.250	0.235
04	Bell housing: SAE #1,				Flywheel: 14”
05	Overall L×W×H: 560×585×764 mm				Dry weight: 365 kg
06	Centre distance: 267.5 mm; 7° down angle on output shaft
07	Recommend engine:
08	Rated propeller thrust: 40 KN

Dimension

Model A302 7°
C	267.5 mm
S
F
L
R
A	7°

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Features

· Meenyon is a leading developer and supplier of high speed gearbox in China.

· Great technology power qualifies Meenyon to prosper and develop in high speed gearbox market.

· Meenyon expects to genuinely assist every client by enhancing quality and support. Inquire!

Product Details

Meenyon's high speed gearbox has been greatly improved in the following details.

Application of the Product

The high speed gearbox developed by our company can play a role in various fields.

Meenyon has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.

Product Comparison

Compared with high speed gearbox of peers, Meenyon's high speed gearbox has the following advantages.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
