MEENYON - Customized Marine Gearboxes Manufacturer & Supplier for 40 Years

High Rpm Gearbox - - Meenyon

Inquiry

more products

Marine Gearbox

Hydraulic Marine Clutch

Hydraulic Marine Clutch

Aftermarket of Marine Gearbox

Marine Unit solution

Send your inquiry

Company Advantages

· Meenyon high rpm gearbox is precisely designed and developed with utmost care.

· The performance and quality of the product have been widely recognized among users.

· Each staff in customer service team of Meenyon are professional.

Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● 5° down angle on output shaft

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

OPTIONS

● Mechanical or electrical remote control

Specification

Item	Description	Model A301 5°
01	Engine speed: 1000-2300 rpm; max 575 hp at 2300 rpm
02	Reduction Ratio :1	1.50	1.96	2.57	2.95
03	Rate (hp/rpm)	0.250	0.250	0.250	0.235
04	Bell housing: SAE #0, #1,				Flywheel: 14”, 16”, 18”
05	Overall L×W×H: 618×585×824 mm				Dry weight: 370 kg
06	Centre distance: 265 mm; 5° down angle on output shaft
07	Recommend engine:
08	Rated propeller thrust: 40 KN

Dimension

Model A301 5°
C	265 mm
S
F
L
R
A	5°

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Features

· Meenyon is a leading manufacturer whose main products are high rpm gearbox.

· The modern production equipment can fully guarantee the quality of high rpm gearbox.

· Meenyon would like to offer customers with top quality and good service. Get info!

Product Details

In the production, Meenyon believes that detail determines result and quality creates brand. This is the reason that we strive for excellence in every product detail.

Application of the Product

The high rpm gearbox produced by our company is widely used in various industries and fields.

In addition to creating excellent Marine Gearbox,Marine Gearbox Parts,Marine Power System Solution,Marine Hydraulic Clutch, Meenyon is also able to provide comprehensive and reasonable solutions for customers.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
