Features

● Durable structure of driving gear bearing

● Tapered roller thrust bearing for output shaft thrust

● Hydraulic clutches of forward and reverse

● 7° down angle on output shaft

● Quality Control System ISO/IATF16949:2016

● Quiet operation with precise gearing.

● Compact design

● Go Home function (emergency bolt application)

OPTIONS

● Mechanical or electrical remote control

Specification

Item	Description	Model A1400 7°
01	Engine speed: 1600-2100 rpm; max 2513 hp at 2100 rpm
02	Reduction Ratio :1		2.93
03	Rate (hp/rpm)		1.180
04	Bell housing: SAE #0, #1, Special		Flywheel: 14”, 16”, 18” Special
05	Overall L×W×H: 826×1300×1250 mm		Dry weight: 1600 kg
06	Centre distance: 340 mm; 7° down angle on output shaft
07	Recommend engine:
08	Rated propeller thrust: 110 kN

Dimension

Model A1400 7°
C	340 mm
S
F
L
R
A	7°

faq

What Is A Marine Gearbox Used For?

A marine gearbox has the functions of speed reduction, forward and reverse, engaging and disengaging as well as bearing propeller thrust. It is used to transfer power from engine to propeller and to form a ship’s marine power unit.

What Are The Main Components Of A Marine Gearbox?

The main components of a marine gearbox include the input shaft, intermediate shaft, output shaft, gears, bearings, clutches and housing.

Company Advantages

· Meenyon marine transmissions is designed by using the finest material and leading technology.

· The product has better durability due to its quality assurance.

· The product has gained much attention from customers owing to the great economic benefits it can bring.

Company Features

· After years of constant efforts, Meenyon has been a strong enterprise involved in producing marine transmissions.

· We are backed by a qualified management team. They hold up the highest production standards to meet or exceed customer expectations in terms of product performance and on-time delivery.

· The ability of Meenyon to produce marine transmissions is in a leading position.

Application of the Product

The marine transmissions produced by Meenyon can be used in many fields.

Meenyon could customize comprehensive and efficient solutions according to customers' different needs.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
