Bulk Marine Transmissions Company
Product details of the marine transmissions
Product Overview
In Meenyon, you can have multiple choices for shapes of marine transmissions. The product is strictly tested by our quality experts on a series of parameters, ensuring its quality and performance. marine transmissions of Meenyon can be used in various scenarios in different fields. This product is increasingly used in the market due to its significant economic benefits.
Product Introduction
Compared with other products in the same category, marine transmissions has more advantages, specifically in the following aspects.
Features
● Durable structure of driving gear bearing
● Tapered roller thrust bearing for output shaft thrust
● Hydraulic clutches of forward and reverse
● Quality Control System ISO/IATF16949:2016
● Quiet operation with precise gearing.
● Compact design
● Go Home function (emergency bolt application)
OPTIONS
● PTO
● Mechanical, pneumatic or electrical remote control
Specification
|
Item |
Description |
Model D300A |
||||||||
|
01 |
Engine speed: 1000-2500 rpm; max 863 hp at 2500 rpm |
|||||||||
|
02 |
Ratio :1 |
4.00 |
4.48 |
5.05 |
5.52 |
5.90 |
6.56 |
7.06 |
7.63 |
|
|
03 |
Rate (hp/rpm) |
0.345 |
0.326 |
0.296 |
0.247 |
0.247 |
0.247 |
0.197 |
0.168 |
|
|
04 |
Bell housing: #0, #1 |
Flywheel: 18”, 16”, 14” |
||||||||
|
05 |
Overall L×W×H: 786×1010×1041 mm |
Dry weight: 880 kg |
||||||||
|
06 |
Centre distance: 355 mm |
|||||||||
|
07 |
Recommend engine: KTA19-M600; TBD234V12 … |
|||||||||
|
08 |
Rated propeller thrust: 60 kN |
|||||||||
Dimension
|
Model D300A |
|
|
C |
355 mm |
|
S |
355 mm |
|
F |
648 mm |
|
L |
475 mm |
|
R |
475 mm |
faq
Company Information
Meenyon, which is Meenyon, is a supplier located in We mainly provide Marine Gearbox,Marine Gearbox Parts,Marine Power System Solution,Marine Hydraulic Clutch. Meenyon runs an excellent, complete and effective sales and technical system. We strive to provide efficient services covering from pre-sales, in-sales, and after-sales, so as to meet customers' needs. We only produce high-quality products. Welcome customers to contact customer service staff for consultation!
